Overview
A 4-motor birthing bed supporting every stage of delivery, with X-ray compatibility and full CPR safety.
Gynaecology
Delivery / Birthing Bed (4-Motor) M-2 DX S
A 4-motor birthing bed supporting every stage of delivery, with X-ray compatibility and full CPR safety.
103,5 cmWidth (with Bumpers)
209,5 cmLength (with Bumpers)
62,5 cmMin. Height
103 cmMax. Height
TSE Certified
Warranted
Fast Delivery
Tech Support
The M-2 DX S is a four-motor birthing bed designed to support every stage of delivery. Silent linear actuators with at least IPX4 protection and a nurse panel with function locking simplify clinical control. The X-ray feature in the backrest supports imaging procedures, while electronic and manual CPR functions enable rapid response in emergencies.
Polypropylene (PP) side rails, detachable panels and a three-section compact-material reclining surface ensure hygiene and durability. A retractable foot-end extension, push bar, calf supports and a waste basin enhance delivery comfort. The 360°-swivel 150 mm central-braking castors, battery, two-part ABS-clad base chassis and nano-ceramic-coated metalwork complete the configuration.
It offers a 62.5-103 cm height range, a 75° backrest, 30° leg, 24° Trendelenburg and 20° reverse Trendelenburg angles, and a 250 kg safe working load.
General Features
- Linear motors with minimum IPX4 protection for silent operation
- Nurse control panel with function lock
- Three-section lying surface made of compact laminate
- X-ray capability in the backrest section
- 360° swivel castors with central braking system (150 mm)
- Polypropylene (PP) side rails with detachable head and foot panels
- Electronic and manual CPR function
- Protective plastic bumpers
- Retractable foot-end extension
- Urine bag holder
- Accessory rail and sockets for attachments
- Waste basin
- Obstetric grab bar
- Calf support
- Battery
- Height-adjustable IV pole
- Nano-ceramic coated, electrostatic powder-coated metal parts
- Backrest auto-regression (slide)
- Angle indicator on the side rails
- Two-section ABS plastic covered base chassis
- Two-section, 28 density mattress
| Width (with Bumpers) | 103,5 cm |
|---|---|
| Length (with Bumpers) | 209,5 cm |
| Min. Height | 62,5 cm |
| Max. Height | 103 cm |
| Mattress Platform (Folded) | 85x144 cm |
| Mattress Platform (Open) | 85x190 cm |
| Backrest Angle | 75° |
|---|---|
| Legrest Angle | 30° |
| Trendelenburg Angle | 24° |
| Reverse Trendelenburg Angle | 20° |
| Safe Working Load | 250 kg |
Positions
The equipment below is available on request in addition to the standard product.
- Colour-customisable head panel and side rail inserts
- Lockable head and foot panels
- Exercise (trapeze) bar
- Patient chart holder
